| Interface |
1 10/100Mbps Auto-Sensing RJ45 Port(Auto MDI/MDIX) |
|---|
| Button |
Reset Button
Range Extender Button
Power On/Off Button |
| External Power Supply |
9VDC / 0.6A |
| Wireless Standards |
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Dimensions ( W x D x H ) |
7.1 x 4.9 x 1.4 in. (181x 125x 36 mm) |
| Antenna Type |
5dBi, Detachable Omni Directional (RP-SMA) |
| WIRELESS FEATURES |
| Frequency |
2.4-2.4835GHz |
| Signal Rate |
11n: Up to 150Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic) |
| Reception Sensitivity |
135M: -69dBm@10% PER
54M: -73dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER |
| Transmit Power |
<20dBm (EIRP) |
| Wireless Modes |
Range Extender / AP Mode |
| Wireless Functions |
WDS Bridge, Wireless Statistics |
| Wireless Security |
SSID Enable/Disable MAC Address Filter 64/128/152-bit WEP Encryption WPA/WPA2/WPA-PSK/WPA2-PSK (AES/TKIP) Encryption |
| Advanced Functions |
Throughput Monitor, DHCP Server |
| OTHERS |
| Certification |
CE, FCC, RoHS |
| Package Contents |
TL-WA730RE
1 detachable Omni directional antenna
Power supply unit
Resource CD
Quick Installation Guide
RJ-45 Ethernet Cable |
| System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, MAC OS, NetWare, UNIX or Linux. |
| Environment |
Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing | |
