| Interface |
4 10/100Mbps LAN Ports
1 10/100Mbps WAN Port
1 USB 2.0 Port |
|---|
| Button |
WPS/Reset Button
WiFi On/Off Button |
| Antenna |
2*5dBi Detachable Omni Directional Antennas (RP-SMA) |
| External Power Supply |
12VDC / 1.0A |
| Wireless Standards |
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Dimensions ( W x D x H ) |
7.6 x 5.1 x 1.3 in.(192 x 130 x 33 mm) |
| WIRELESS FEATURES |
| Frequency |
2.4-2.4835GHz |
| Signal Rate |
Up to 300Mbps |
| Reception Sensitivity |
270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER |
| Transmit Power |
CE:
<20dBm(2.4GHz)
FCC:
<30dBm |
| Wireless Functions |
Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics |
| Wireless Security |
64/128/152-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK |
| SOFTWARE FEATURES |
| Quality of Service |
WMM, Bandwidth Control |
| WAN Type |
Dynamic IP/Static IP/PPPoE/
PPTP/L2TP/BigPond |
| Management |
Access Control
Local Management
Remote Management |
| DHCP |
Server, Client, DHCP Client List,
Address Reservation |
| Port Forwarding |
Virtual Server, Port Triggering, UPnP, DMZ |
| Dynamic DNS |
DynDns, Comexe, NO-IP |
| VPN Pass-Through |
PPTP, L2TP, IPSec(ESP Head) |
| VPN |
5 IPsec VPN Tunnels |
| Access Control |
Parental Control, Local Management Control, Host List, Access Schedule, Rule Management |
| Firewall Security |
DoS, SPI Firewall
IP Address Filter/MAC Address Filter/Domain Filter
IP and MAC Address Binding |
| Protocols |
Support IPv4 and IPv6 |
| USB Sharing |
Support Samba/FTP/Media Server/Printer Connection |
| Guest Network |
2.4GHz Guest Network x1 |
| OTHERS |
| Certification |
CE, FCC, RoHS |
| Package Contents |
TL-WR842ND
2 Detachable Omni Directional Antennas
Power Supply Unit
Resource CD
RJ-45 Ethernet Cable
Quick Installation Guide |
| System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, Windows 8/8.1/10
MAC OS, NetWare, UNIX or Linux |
| Environment |
Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing | |
