| Interface |
1 10/100Mbps WAN/LAN Port
1 Micro USB Port
1 Reset Button |
|---|
| Wireless Standards |
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Dimensions ( W x D x H ) |
2.2 x 2.2 x 0.7 in. (57 x 57 x18 mm) |
| Antenna Type |
On-Board |
| WIRELESS FEATURES |
| Frequency |
2.4-2.4835GHz |
| Signal Rate |
11n: Up to 150Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic) |
| Reception Sensitivity |
135M:-70dBm@10%PER
65M:-73dBm@10%PER
54M:-76dBm@10%PER |
| Transmit Power |
CE:
<20dBm(2.4GHz)
FCC:
<30dBm |
| Wireless Modes |
AP Mode, Router Mode ,Client Mode,
Repeater Mode, Bridge Mode |
| Wireless Functions |
Enable/Disable Wireless Radio, WDS Bridge, WMM,
Wireless Statistics |
| Wireless Security |
64/128/152-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| SOFTWARE FEATURES |
| Quality of Service |
WMM, Bandwidth Control |
| WAN Type |
Dynamic IP/Static IP/PPPoE/
PPTP/L2TP |
| Management |
Local Management
Remote Management |
| DHCP |
Server, Client, DHCP Client List,
Address Reservation |
| Port Forwarding |
Virtual Server, Port Triggering, UPnP, DMZ |
| Dynamic DNS |
DynDns, Comexe, NO-IP |
| VPN Pass-Through |
PPTP, L2TP, IPSec (ESP Head) |
| Firewall Security |
DoS, SPI Firewall
IP Address Filter/MAC Address Filter/Domain Filter
IP and MAC Address Binding |
| OTHERS |
| Certification |
CE, FCC, RoHS |
| Package Contents |
TL-WR702N
Power Adapter
USB Cable
Ethernet cable
Quick Installation Guide
Resource CD |
| System Requirements |
Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, Windows8/ 8.1/10
MAC® OS, NetWare®, UNIX® or Linux |
| Environment |
Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing | |
